40X 1000X Trinocular Phase Contrast Microscope Bright Field Light WF10X/20mm

    Buy cheap 40X 1000X Trinocular Phase Contrast Microscope Bright Field Light WF10X/20mm from wholesalers

    Buy cheap 40X 1000X Trinocular Phase Contrast Microscope Bright Field Light WF10X/20mm from wholesalers
    • Buy cheap 40X 1000X Trinocular Phase Contrast Microscope Bright Field Light WF10X/20mm from wholesalers

    40X 1000X Trinocular Phase Contrast Microscope Bright Field Light WF10X/20mm

    Ask Lasest Price
    Brand Name : Phidix
    Model Number : M17103
    Certification : IATF16949,CE
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union
    Supply Ability : 1000 PCS/Month
    Delivery Time : 15-20 Work Days
    • Product Details
    • Company Profile

    40X 1000X Trinocular Phase Contrast Microscope Bright Field Light WF10X/20mm


    40X-1000X Binocular Phase Contrast Microscope


    M17103 40X-1000X Binocular Phase Contrast Microscope. M17103 is designed as phase-contrast microscope, which is an optical-microscope technique that converts phase shifts in light passing through a transparent specimen to brightness changes in the image. Phase shifts themselves are invisible, but become visible when shown as brightness variations.


    Features:


    - Uniform illumination with consistent color temperature.

    - Enables users to remain comfortable during long periods of routine microscopy observations.

    - Competent for scientific research, medicine, industry, agriculture and education.


    ItemDescription / Value
    Optical system:UCIS Infinity independent achromatic optical system
    Head:Seidentopf binocular head 30° inclined, 360 ° rotatable interpupillary distance 52-75mm
    Eyepiece:WF10X/20mm
    Objective:

    Infinity Achromatic objective 4X;

    Infinity Achromatic phase-contrast objective 10X;

    Infinity Achromatic phase-contrast objective 40X;

    Infinity Achromatic phase-contrast objective 100X;

    Nosepiece:Four-hole converter
    Magnification:40X~l000X
    Focusing mechanism:Coaxial coarse and fine focus mechanism with markings. Fine focus sensitivity 0.001mm
    Light source:

    6V20W halogen illumination, brightness adjustable;

    6V30W halogen illumination, brightness adjustable;

    3W LED, brightness adjustable

    Condensor:N.A. 1.25 Phase contrast condenser, center adjustable
    Stage:Mechanical stage with double layers, 156mmx138mm, movement range 76mmx 52mm
