Achromatic Digital Microscope 1000x WF10X/18mm Biological Binocular Microscope

1000X Binocular Biological Comparison Microscope

M16102 1000X Binocular Biological Comparison Microscope. M16102 biological comparison microscope is used to analyze side-by-side specimens. It consists of two microscope connected to an optical bridge, which gives choice of 4 kinds of observation view field: full left, full right, split and overlapping image. It is designed for identifying object's structure, comparing similarities and differences between specimens, such as pathological slides, biological slides and so on. It is an ideal instrument for teaching, biological and medical fields etc.

Features:

- It can be used to observe two different specimens at the same time.

- Choice of 4 kinds of observation view field: full left, full right, split and overlapping image.

- With excellent infinity optical system and stable stage.

- Used for teaching, biological and medical fields etc.

Item	Description / Value	Configuration
Optical system:	Achromatic optical system	●
View tube:	Trinocular, 30° Tilt, 360°rotatable. Splitting ratio: 100: 0 IPD adjustment: 54mm ~ 75mm. Diopter adjustment: ±5 diopters.	●
Eyepiece:	High eye level WF PL10 × (Φ22mm)	●
Objective:	Light field: Flat field achromatic objective lens: 4X, 10X, 40X,100X	●
Objective:	Optional: 20X, 50X	○
Nosepiece:	Four-hole converter	●
Comparison viewing:	Full left image. Full right image. Part of left & right images. Left & right superposition image.	●
Comparison head:	Magnification of comparison head: 1X, View field: 20mm.	●
Focusing mechanism:	Coaxial positioning system. Tightness and height limitation of coarse regulation are adjustable. Fine adjustment accuracy: 0.002mm, moving range adjustable.	●
Light source:	Transmission Kohler illumination system; default center, brightness adjustable. 6V/30W halogen lamp	●
Light source:	3W LED.	○
Condenser:	Light field: NA1.25 /0.22 swing out achromatic condenser	●
Filter:	Yellow, green, blue, neutral filter.	●
Power supply:	AC90V~240V, 50Hz/60Hz.	●

Remarks: ● Means Current Configuration ○ Means Optional
